Industry Solutions
Aviation MRO & Ground Support
Life vests, tools and rotables checked before the aircraft is released.
Where the day goes wrong
The life-vest check runs seat by seat.
A cabin check means opening every stowage to confirm a sealed vest is where the seat card says it should be, then signing a sheet that is filed and rarely read again. Read the cabin from the aisle and the check becomes a walk-through with a record attached, instead of a hand count against paper.
Why it is hardA cabin is a confined RF space: seats, stowage and metal structure all in the near field, and a vest that is inside a stowage under a seat. The useful property is that the read does not need line of sight, so a position that answers is confirmed and a position that stays silent is the one to open. That turns a manual check of every seat into a directed check of the exceptions, with the record written as the walk is made.
Our partThe JMDS65 handheld is what does the walk, and the read is written as the aisle is walked rather than transcribed afterwards.
A tool leaves the bay and does not come back.
A torque wrench or a socket set goes out against a board, and at release the crew walks the bay counting what should be on the wall. Read the cabinet at issue and at return, and what is still out is known before the panel goes back on.
Why it is hardTool control is an issue-and-return transaction where the tools are steel, so it is the on-metal case plus a controlled access point. The cabinet reads the drawer set at issue and at return, so what is still out is known from the cabinet rather than from a count at the wall at release.
Our partThe JNI-TM02 and JNI-TM03HZ cabinets record every take against a badge, which is what makes release a check rather than a count.
The rotable and its record drift apart.
A part comes off, goes for repair and returns to a different shelf, while the paperwork catches up days later. Read the part at each handover and the location, the service history and the release paperwork move together.
Why it is hardA rotable moving between a bay, a repair shop and a shelf is a chain of handovers, and the chain holds only if the part carries an identity that survives the journey. ATA Spec 2000 Chapter 9-5 is the industry reference for part marking and SAE AS5678 for tag performance; our part is the reading and identification layer that works alongside the records you keep.
Our partThe JNI-TM08 and JNI-TM09 shelves keep a live count in stores, and a JNR-E401N with JNA series antennas covers the bay read where a fixed point suits the layout better than a handheld.
How RFID reads a cabin
Aviation MRO is the case where the read has to work in a space designed around people rather than around radio. A cabin is full of metal, close-packed, and screened by the structure itself, so read range is short and the value is not distance - it is the fact that a sealed stowage can be checked without being opened. That is what converts a seat-by-seat inspection into a walk-through that produces a record. Part marking and tag performance follow the aviation references the industry already uses.
- ATA Spec 2000 Ch. 9-5 / SAE AS5678
- A position that stays silent is the one opened
- On-metal tags for steel tooling
We supply the handheld, the cabinets, the readers and the antennas, and we survey the bay and the stores before the order.
What goes on the bay
Tool and test-gear control
Cabinets record every take against a badge, so the tools still out are known before release.
View JNI-TM03HZ
Bay and stores reading
Read parts and kits where they move, with JNA series antennas.
JNR-E401N · JNR-E801N · JNA series UHF antennas
View the JNR-E family
Walk-through checks
A handheld and an 8-inch UHF tablet for cabin rounds and stock checks.
View JMDT80What hardware does this industry usually deploy?
A working configuration for this industry, taken from the equipment listed above. The band column gives the UHF RFID standards the hardware is built to.
| Role on site | Recommended models | UHF band | What it does |
|---|---|---|---|
| Tool and test-gear control | JNI-TM02 · JNI-TM03HZ | 902-928 MHz (US) / 865-868 MHz (EU) | Cabinets record every take against a badge, so the tools still out are known before release. |
| Open storage | JNI-TM08 · JNI-TM09 | 902-928 MHz (US) / 865-868 MHz (EU) | A live count on shelves and open racks, with a weighing option. |
| Bay and stores reading | JNR-E401N · JNR-E801N · JNA series UHF antennas | 902-928 MHz (US) / 865-868 MHz (EU) | Read parts and kits where they move, with JNA series antennas. |
| Walk-through checks | JMDS65 · JMDT80 | 902-928 MHz (US) / 865-868 MHz (EU) | A handheld and an 8-inch UHF tablet for cabin rounds and stock checks. |
How it runs
- Emergency-equipment check Each stowage position is read on the walk-through, and a unit that does not answer is the one that gets opened.
- Tool issue and release A badge opens the cabinet, and at release the tools still out are read from the cabinet rather than counted by hand.
- Rotable and stock control Parts are read at the shelf and at the handover, so the shelf, the service record and the paperwork agree.
Questions we get
Does an inspection still have to open every stowage?
Do we have to replace our maintenance system?
Which aviation references apply?
Tell us what you release.
Send the fleet or the bay, how many tools and rotables you control, and how the release check runs today, and we will come back with a read-point plan and a parts list.
