Mobile Computers · JMDT80
8-Inch Rugged Android Tablet with Built-in Barcode Scanner
An industrial Android tablet for warehouse, field service and manufacturing — MIL-STD-810H tested, built-in Zebra SE4710 barcode scanning, hot-swap 6050 mAh battery, IP68, 5G connectivity and Wi-Fi 6 on a 600-nit display.
Applications
One Tablet. Three Workflows.
The largest screen in the JNXRFID rugged lineup with a built-in Zebra scan engine — built for the places where a phone is too small and a laptop is too fragile.
Warehouse & Logistics
Dock operations and forklift mounting, asset management and cycle counting with integrated scanning — and a hot-swap 6,050 mAh battery that keeps the shift running without a reboot.
Field Service
Work orders and digital SOPs, asset inspection forms, remote-assistance video calls and customer signature capture — on a 600-nit 8-inch screen with active stylus support.
Manufacturing
Shop-floor dashboards, quality checklists, MES/WIP data entry and machine maintenance logs — with glove/wet touch built for plant conditions, plus JMDT80Ex for intrinsically-safe zones.
Ideal For —
- Field service — work orders, digital SOPs, remote assistance, signature capture
- Manufacturing — shop-floor dashboards, quality checklists, MES/WIP data entry
- Warehouse & logistics — dock operations, forklift mounting, asset management
⚠️ Consider Alternatives If —
The JMDT80 brings a big 8-inch 1200x1920 IPS display to demanding field, plant, and warehouse environments. At just 11.6mm thick and 500g, it's thinner than many rugged tablets while still meeting MIL-STD-810H testing, IP68 sealing and 1.3m drop specifications.
Zero downtime is built in: a 6,050 mAh hot-swappable battery keeps crews working through long field shifts without rebooting. Active stylus support and glove/wet touch make precision annotation and gloved operation practical, while the physical scan button and integrated Zebra SE4710 / SE55 / CM60 imagers turn the tablet into a large-screen scanner when needed.
Specifications
| Operating System | Android 16 (GMS certified; upgradable to Android 19) |
|---|---|
| Processor | Octa-core, 2 x Cortex-A78 @ 2.4 GHz + 6 x Cortex-A55 @ 2.0 GHz |
| Memory / Storage | Standard: 6 GB RAM + 64 GB ROM; Premium: 8 GB RAM + 128 GB ROM |
| Display | 8" IPS, 1200 x 1920, 600 nits |
| Touch Panel | Multi-point capacitive, glove / wet-hand operation, active stylus support |
| Button | Power, volume, physical scan button, programmable button, home button (optional fingerprint) |
| Scan Engine | Zebra SE4710 / SE55 / CM60 |
| Camera | Rear: 13 MP PDAF (Premium: 48 MP PDAF); Front: 5 MP FF |
| WWAN | 5G (optional 4G LTE) |
| WLAN | IEEE 802.11 a/b/g/n/ac/ax (Wi-Fi 6), 2x2 MIMO, IPv4/IPv6, fast roaming |
| Bluetooth | Bluetooth 5.2 (BLE) |
| GNSS | GPS + GLONASS + BeiDou + Galileo + AGPS |
| NFC | 13.56 MHz, ISO14443A/B, ISO15693, up to 30 mm |
| SIM | 1 nano-SIM + 1 MicroSD; eSIM optional |
| Battery | 3.8 V / 6,050 mAh; optional hot swap (model BAT-806001, shared with JMDT80L) |
| Ingress Protection | IP68 |
| Certifications | GMS (Android 16) • CE • Cyber Security • EU Common Charger Directive (EN IEC 62680-1-3) • CCC • RoHS • WEEE • REACH • IP68 (IEC 60529) • MIL-STD-810H |
| Battery Certifications | UN38.3 & MSDS • CCC • CB (BAT-806001 battery pack, shared by JMDT80 / JMDT80L) |
| Certifications shown apply to the 5G model JMDT80. JMDT80L (4G LTE) certifications are in progress — contact us for the current status. | |
| Drop Protection | Multiple 1.3 m drops to concrete |
| Operating Temp | -10°C to +50°C |
| Storage Temp | -20°C to +60°C |
| Humidity | 0% to 95% non-condensing |
| ESD Protection | ±15 kV air, ±8 kV contact |
| Audio | Dual superlinear speakers, dual microphones, vibrator, indicator light x 2 |
| Sensors | Tri-accelerometer, light, distance, gyro, e-compass; optional fingerprint |
| I/O Ports | USB Type-C (OTG + charging + earphone), bottom Pogo Pin charging |
| Weight | 500 g (with battery) |
| Dimensions | 216 x 134 x 11.6 mm |
| Accessories | USB cable, 5V/2A adapter (standard); Single Charging Home Base, Quad Bay Charging Base, Quad Battery Charger, active stylus, wrist/neck/hand straps, leather cover (optional) |
| Model Variants | JMDT80 (standard; IP68, 1.3 m drop, -10°C to +50°C) • JMDT80Ex (intrinsically safe; Ex ib IIC T4 Gb / Ex ib IIIC T130°C Db; Certificate CCRI 25.7223X) • JMDT80HC (healthcare / disinfectant-ready; resists alcohol, quaternary salt, peroxide) • JMDT80L (4G LTE value model; certifications in progress) |
Why Choose JMDT80
The Big Screen for Big Jobs
Slim, rugged, and ready for the hardest environments — including explosion-proof and healthcare models — with hot-swap power and enterprise connectivity.
8" 1200x1920 600-Nit Display
1200x1920 IPS display with active stylus and glove/wet touch keeps annotations, forms and controls comfortable in field, plant and retail conditions.
Slim & Rugged
Just 11.6mm thick and 500g — thinner than many rugged tablets while still meeting MIL-STD-810H, IP68 and 1.3m drop specifications.
Hot-Swap Power
6050mAh hot-swappable battery (BAT-806001) keeps crews working through long field shifts without rebooting; T80Ex and T80HC variants for special environments.
5G + Wi-Fi 6 + GNSS
5G, Wi-Fi 6 (2x2 MIMO), and GPS/GLONASS/BeiDou/Galileo + AGPS deliver the connectivity and location accuracy expected from enterprise tablets.
Built-in Barcode Scanner
Zebra SE4710 / SE55 / CM60 imager with a physical scan key — large-screen barcode capture for warehouse counts and field asset checks, no sled required.
Available in standard, intrinsically-safe, and healthcare configurations. Request an evaluation unit.
FAQ
JMDT80 Questions, Answered
Straight answers for specification and compliance checks.
Does the JMDT80 have a built-in barcode scanner?
Yes. The JMDT80 integrates a Zebra SE4710, SE55 or CM60 imager behind a physical scan key, so the 8-inch Android tablet doubles as a large-screen barcode scanner for cycle counts, asset checks and dock operations.
Is this an 8-inch Android tablet with a Zebra scan engine?
Yes — an 8-inch Android tablet (1200x1920, 600 nits) available with Zebra SE4710/SE55/CM60 scan engines, delivering proven enterprise scan performance on a large touchscreen.
Does the JMDT80 support 5G connectivity?
Yes. The WWAN configuration supports 5G (with optional 4G LTE), plus Wi-Fi 6 2x2 MIMO, Bluetooth 5.2 and multi-constellation GNSS.
Can the tablet be wiped with disinfectant for hospital use?
The JMDT80HC healthcare model is disinfectant-ready and resists repeated wiping with alcohol, quaternary ammonium and peroxide wipes; IP68 sealing allows rinsing after exposure. It is built for hygiene-sensitive healthcare and laboratory settings, not as a certified medical device.
Is the JMDT80 rugged enough for warehouse and forklift use?
Yes. IP68 sealing, multiple 1.3 m drops to concrete, a hot-swap 6050 mAh battery and optional forklift mounting accessories make it suitable for warehouse dock operations, cycle counting and asset management.
What JMDT80 models are available?
Three: JMDT80 (standard rugged), JMDT80Ex (intrinsically safe, Ex ib IIC T4 Gb, CCRI 25.7223X) and JMDT80HC (disinfectant-ready healthcare model).
Side-by-Side Battle Card
JMDT80 vs Tier-1 8" Enterprise Tablets
A one-document battle card covering the specs that drive uptime and total cost of ownership: full IP68 sealing, built-in barcode scanning, hot-swap battery power, 5G + Wi-Fi 6 connectivity, and Ex / healthcare variants for special environments — typically at 1/3–1/2 the acquisition cost of Tier-1 devices. Preview it below or download the PDF.
Ready to evaluate JMDT80?
Request a quote, evaluation terms, or a technical consultation.
