Mobile Computers · JMDS65
6.5-Inch 5G Rugged Android PDA with Built-in Zebra Scanning
HD+ 5G/4G full-touch mobile computer with Zebra SE scan engines for near-to-far reading, IP68 ruggedness and 5050 mAh all-day battery. Available in 5G, 4G LTE and intrinsically-safe models.
Applications
One PDA. Three Workflows.
A 6.5-inch HD+ screen with built-in Zebra scanning and 5G/4G connectivity — one device for the warehouse floor, the store and the field.
Warehouse & Logistics
Scan. Track. Move faster. Receiving and put-away scanning, pick-to-cart / voice picking, cycle counts and cross-dock verification — with a screen large enough to show the full line item at a glance.
Retail In-Store
Scan for product information. Store inventory lookup, click-and-collect picking, shelf replenishment and line-busting POS — check price, print labels and assist customers on the spot.
Field Service & Delivery
Capture. Confirm. Deliver. Proof-of-delivery capture, asset inspections and route operations — powered by the removable 5050 mAh battery and 5G connectivity.
Watch the JMDS65 drop test — more than 30 consecutive 1.5 m drops onto concrete, all passed.
Ideal For —
- Field service and route operations needing a large screen and fast scanning
- Retail & omnichannel stores — inventory lookup, click-and-collect, line-busting POS
- Warehouse and distribution teams that move between receiving and shipping
⚠️ Consider Alternatives If —
The JMDS65 is built around one idea: a 6.5-inch window into every workflow. Its HD+ IPS display gives workers the screen real estate they expect from large-screen enterprise devices, while glove and wet-touch support keeps them productive in demanding conditions.
Connectivity is your choice — 5G for future-ready speed on the JMDS65, or the same 6.5-inch experience on cost-effective 4G LTE with the JMDS65L. A Zebra SE4710 through SE55 / CM60 imager line-up delivers near-to-far scan range, and IP68 sealing plus a documented drop test — more than 30 drops from 1.5 m onto concrete, run without a protective boot — covers the rugged baseline of Tier-1 enterprise devices.
Specifications
| Operating System | Android 16 (GMS certified; upgradable to Android 18) |
|---|---|
| Processor | Octa-core, 2 x A76 @ 2.2 GHz + 6 x A55 @ 2.0 GHz |
| Memory / Storage | Standard: 6 GB RAM + 64 GB ROM; Premium: 8 GB RAM + 128 GB ROM |
| Display | 6.517" HD+, 1600 x 720 IPS |
| Touch Panel | Multi-point capacitive, glove / wet-hand operation |
| Scan Engine | Zebra SE4710 / SE4720 / SE4770 / SE4750 / SE55 / CM60 |
| Camera | Rear: 13 MP PDAF; Front: 5 MP FF; LED flash |
| WWAN | 5G (optional 4G LTE) |
| WLAN | IEEE 802.11 a/b/g/n/ac/ah/i/r/k/v/w (Wi-Fi 5), IPv4/IPv6, fast roaming |
| Bluetooth | Bluetooth 5.2 (BLE) |
| GNSS | GPS + GLONASS + BeiDou + Galileo + AGPS |
| NFC | 13.56 MHz, ISO14443A/B, ISO15693, up to 30 mm |
| SIM | Dual nano-SIM or 1 nano-SIM + 1 MicroSD; eSIM optional |
| Battery | 3.8 V / 5,050 mAh removable Li-ion (model BAT-655001, shared with JMDS65L) |
| Ingress Protection | IP68 |
| Certifications | CE • Cyber Security • EU Common Charger Directive (EN IEC 62680-1-3) • CB • RoHS • GMS (Android 16) • IP68 (IEC 60529) • MIL-STD-810H |
| Battery Certifications | UN38.3 & MSDS • CCC • CB (BAT-655001 battery pack, shared by JMDS65 / JMDS65L) |
| Certifications shown apply to the 5G models. The 4G LTE variant JMDS65L carries a reduced certification set — contact us for the current certification matrix. | |
| Drop Protection | More than 30 verified drops from 1.5 m onto concrete — all passed, tested without a protective boot |
| Operating Temp | -20°C to +50°C |
| Storage Temp | -40°C to +70°C |
| Humidity | 0% to 95% non-condensing |
| ESD Protection | ±15 kV air, ±8 kV contact |
| Audio | Speaker, dual microphones, vibrator, receiver, indicator light |
| Sensors | Tri-accelerometer, light, distance, Hall, gyro, e-compass |
| I/O Ports | USB Type-C (OTG + charging + earphone), bottom Pogo Pin charging |
| Weight | 285 g (with battery) |
| Dimensions | 175 x 78.5 x 14.5 mm |
| Accessories | USB cable, 5V/2A adapter (standard); hand strap, rugged boot, scan handle, quad battery charger, single charging home base (optional) |
| Model Variants | JMDS65 (5G flagship; MT6833 octa-core, 2 x A76 @ 2.2 GHz + 6 x A55 @ 2.0 GHz) • JMDS65L (4G LTE value; MT6769 octa-core, 2 x A75 @ 2.0 GHz + 6 x A55 @ 1.8 GHz) • JMDS65Ex (intrinsically safe 5G; Ex ib IIC T4 Gb / Ex ib IIIC T130°C Db; Certificate CQC 26.0037X) |
Why Choose JMDS65
A Large-Screen Workhorse for Warehouse, Retail & Field Operations
One device family spanning 5G, 4G LTE, and intrinsically-safe models — the JMDS65 delivers the screen, scan range, and ruggedness of Tier-1 enterprise handhelds at a pragmatic cost.
6.5" HD+ Display
1600x720 IPS screen delivers flagship-class screen real estate, with glove and wet-hand touch support for demanding work environments.
5G or 4G, Your Choice
MT6833 5G flagship; JMDS65L 4G LTE value model; Wi-Fi 5 with fast roaming keeps real-time operations connected.
Zebra SE Scan Range
Choose SE4710 through SE55 / CM60 imagers — near-to-far scanning flexibility matching Tier-1 device portfolios.
All-Day 5050mAh Battery
Removable battery supports full-shift use; the intrinsically-safe JMDS65Ex extends operations into hazardous areas.
Request an evaluation unit.
Side-by-Side Battle Card
JMDS65 vs Tier-1 Touch Terminals
A one-document battle card comparing the JNXRFID JMDS65 and JMDD40 with the Tier-1 touch-terminal class — same-class Zebra SE scan engines, full connectivity, newer Android, IP67/IP68 ruggedness, and roughly 1/3–1/2 the acquisition cost. Preview it below or download the PDF.
FAQ
JMDS65 Questions, Answered
Straight answers drawn from the specification table above.
Which operating system does the JMDS65 run?
Android 16 (GMS certified; upgradable to Android 18)
What processor does the JMDS65 use?
Octa-core, 2 x A76 @ 2.2 GHz + 6 x A55 @ 2.0 GHz
How much memory and storage does the JMDS65 have?
Standard: 6 GB RAM + 64 GB ROM; Premium: 8 GB RAM + 128 GB ROM
Which scan engine does the JMDS65 use?
Zebra SE4710 / SE4720 / SE4770 / SE4750 / SE55 / CM60
What battery does the JMDS65 use?
3.8 V / 5,050 mAh removable Li-ion (model BAT-655001, shared with JMDS65L)
Can the JMDS65 be evaluated before a volume order?
Yes. The JMDS65 is available as a single evaluation unit before volume orders, with customization available on request. Contact us for current lead time and evaluation terms.
